CB/T 3842 B Square Type Quick Acting Watertight Small Hatch Cover Marine Outfitting
Product Details:
| Place of Origin: | China |
| Brand Name: | Zhongyuan |
| Certification: | CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc. |
| Model Number: | Standard and Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | As per quotation |
| Packaging Details: | Pallet or Customized |
| Delivery Time: | As per offer |
| Payment Terms: | TT, L/C, Etc. |
| Supply Ability: | Satisfy clients needs |
|
Detail Information |
|||
| Standard: | CB/T 3842-2000 | Material: | Mild Steel, Stainless Steel |
|---|---|---|---|
| Packing Materials: | Neoprene, NBR ,Hi NBR | Test: | Hydraulic Pressure Test |
| Dimension: | As Standard Or Customized, As Client’s Drawing, | Open Type: | Hand Wheel Quick Operate |
| Application Type: | Water-tight, Gas Tight | Closing Type: | Hinged With Spring |
| Surface Treatment: | Sandblasting To S2.5 + One Layer Of Epoxy Shop Primer, Galvanized, Polished, Customized Surface Treatment Available. | Classification Certificates: | CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA |
Product Description
CB/T 3842 B Square Type Quick Acting Watertight Small Hatch Cover
Description:
CB/T 3842-2000 type B quick acting small hatch cover is square type watertight hatches. It is designed for hydraulic pressure 0.2MPa. Higher pressure can be designed case by case subject to class approval. The standard height of the coaming is 200mm. Higher height can be produced with thicker and stronger plate. It can be open from both side with quick action handwheel. Spring hinge makes operation of the hatches easily.
Main Technical Specification:
- Standard: CB/T 3842-2000
- Material: Mild Steel, Stainless Steel,
- Packing Materials: Neoprene, NBR ,Hi NBR,
- Test: Hydraulic Pressure Test
- Dimension: As Standard or Customized, As client’s drawing,
- Application Type: Water-tight, Gas Tight,
- Open Type: Hand Wheel Quick Operate
- Closing Type: Hinged with Spring
- Surface treatment: sandblasting to S2.5 + one layer of epoxy shop primer, Polished, Galvanized, customized surface treatment available.
- Classification Certificates: CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA.
Main Technical Parameters:
|
Nominal Size A x A |
Deck Cutout |
Coaming Inner Size A2 x A2 |
Cover Plate Size A3 x A3 |
Cover Plate Thickness t |
Coaming | Weight | |
| Thickness | Height | ||||||
| 600x600 | 640x640 | 670x670 | 720x720 | 12 | 12 | 200 | 310 |
| 700X700 | 40X740 | 770x770 | 820X820 | 340 | |||
| 800X800 | 40x840 | 870X870 | 920x920 | 380 | |||
Drawing of CB/T 3842 B Square Type Quick Acting Watertight Small Hatch Cover Marine Outfitting
