Boat Hydraulic Mooring Capstan Winch
Product Details:
| Place of Origin: | China |
| Brand Name: | Zhongyuan |
| Certification: | CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc. |
| Model Number: | Standard and Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | As per quotation |
| Packaging Details: | Pallet or Customized |
| Delivery Time: | As per offer |
| Payment Terms: | TT, L/C, Etc. |
| Supply Ability: | Satisfy clients needs |
|
Detail Information |
|||
| Function: | Mooring | Working Load: | 2KN To 250KN |
|---|---|---|---|
| Warping Head Diameter: | 200-500 Mm | Speed(m/min): | 5-30m/Min |
| SW Rope Diameter: | 11 - 46 (mm) | Material: | Carbon Steel, Casting, Stainless Steel |
| Power: | Hydraulic Driven | Control: | Local Or Remote Control |
| Classification Certificates: | CCS, NK, BV, ABS, DNV, LR, KR, IRS, RS, RINA | ||
Product Description
Boat Hydraulic Mooring Capstan Winch
Description:
Boat hydraulic mooring capstan winch plays a vital role in the ship's departure operations, helping the crew to easily retract the mooring ropes. The design of our hydraulic capstan features a drum-like structure of rope or steel cable that rotates around it, and a powerful motor drives its rotation. Able to withstand high loads and provide stable, controllable traction, fast retraction speed, speed can be adjusted, divided into normal tension speed and free retraction speed, with hydraulic brake, hydraulic system is equipped with balance valve and safety valve, warping head is made of precision casting process of steel castings to ensure the quality of castings, shaft is made of alloy steel, gearbox with suitable speed ratio and high torque hydraulic motor.
Main Features
- Responsive proportional operating valve allows the operator to precisely control the equipment for meticulous operation
- Hydraulic motor with high torque, high load and provide stable, controllable traction,
- The retraction speed is fast, and the speed can be adjusted, which is divided into the speed of normal tension and the speed of free retraction.
- With hydraulic brake, the hydraulic system is equipped with balance valve and safety valve,
- High quality casting steel warping head
- The shaft is made of alloy steel, a gearbox with a suitable speed ratio and a hydraulic motor.
- Application: Construction, Maritime, Mining & Transportation, Heavy Industrial Lifting & Traction
Main Technical Specification:
- Function: Ship mooring, also can be used for pulling, lifting, hauling and extracting in other industry;
- Working Load: 2KN to 300KN
- Warping Head Diameter: 250-800 mm,
- Configuration:Vertical type, horizontal type, with raised seat, flush seat with deck;
- Speed(m/min):5-30m/Min, multiple speed choice,
- Rope Dia. SWR 11 - 46 (mm), Synthetic Rope: 28 - 80 (mm)；
- Material: C-Mn casting steel for Warping head, Mild Steel for seat, Alternative Stainless Steel (Polished),
- Power: Hydraulic motor driven
- Control: Lever control valve, hydraulic proportional valve local or Electric proportional valve remote Control;
- Surface treatment: Sa2.5 grit blasting, marine coat;
- Certificates: Classification BV, ABS, DNV, LR, KR, IRS, RS, RINA, CCS, NK, Etc.
Main Technical Parameters:
|
Working Load (KN) |
Warping Head Dia. (mm) |
Speed (m/min) |
Steel Wire Rope Dia.,(mm) | Synthetic Rope Dia.(mm) |
Hydraulic Motor (kw) |
| 2 | 250 | 5-30 | 11 | 28 | 3.5 |
| 5 | 250 | 5-30 | Ф11 | 28 | 5.5 |
| 10 | 300 | 5-30 | Ф11 | 28 | 7.5 |
| 15 | 300 | 5-30 | Ф13 | 32 | 11 |
| 20 | 350 | 5-30 | Ф15 | 32 | 15 |
| 30 | 350 | 5-30 | Ф17.5 | 32 | 18.5 |
| 50 | 400 | 5-30 | Ф20.5 | 40 | 30 |
| 70 | 400 | 5-30 | Ф26 | 45 | 45 |
| 100 | 450 | 5-30 | Ф28 | 50 | 55 |
| 120 | 450 | 5-30 | Ф32.5 | 55 | 75 |
| 150 | 450 | 5-30 | Ф36.5 | 65 | 90 |
| 200 | 500 | 5-30 | Ф40 | 80 | 110 |
| 250 | 500 | 5-30 | Ф46 | 80 | 110 |
Please kindly provide the following basic parameters in your Request for quotation:
1. Is it used for mooring or anchoring?
2. Do you need a vertical capstan or horizontal capstan?
3. Rated load or pull force:
4. Rope/chain diameter and drum capacity (mm×m):
5. Rated speed:
6. Driven type (electric/hydraulic):
7. Voltage, frequency and phrase:
8. What is the purpose and working environment of the marine capstan?
9. Will you use it on the deck or on the shore?
- Do you have any other special requirements?
